SINUMERIK 808D ADVANCED brings impetus into basic turning and milling machines. CNC technology from the global leader – teamed-up with a revolutionary operating concept – make the SINUMERIK 808D ADVANCED the perfect entry point into the world of CNC.
The SINUMERIK 808D ADVANCED control is a panel-based CNC for the lower performance range. The compact and user-friendly entry-level solution is used for basic turning and milling applications. Features such as simple operation, commissioning and maintenance, in conjunction with an optimum cost position, represent the perfect basis for equipping entry- level CNC machines.
he following composition of an equipment package is an example for a vertical machining center with:
|
Designation |
Quantity |
Article No. |
|---|---|---|
|
SINUMERIK CNC |
||
|
SINUMERIK 808D ADVANCED M PPU 161.3 horizontal, layout English or Chinese1) |
1 |
6FC5370-2AM03-0❑A0 |
|
SINUMERIK 808D MCP horizontal, layout English or Chinese2) |
1 |
6FC5303-0AF35-0❑A0 |
|
Electronic handwheel, with front plate 120 mm × 120 mm, with setting wheel, 5 V DC, RS 422 |
1 |
6FC9320-5DB01 |
|
Terminal strip converter 50-pole |
1 |
6EP5406-5AA00 |
|
Cable set, 50-pole ribbon cable, with insulation displacement connectors, 50-pole |
1 |
6EP5306-5BG00 |
|
Stabilized power supply, SITOP PSU200M 24 V DC, 5 A |
1 |
6EP1333-3BA10 |
|
Pre-assembled bus cable PPU 161.3 – SINAMICS V70, length 5 m |
1 |
6FC5548-0BA20-1AF0 |
|
Pre-assembled bus cable SINAMICS V70 – SINAMICS V70, length 0.25 m |
2 |
6FC5548-0BA20-1AA2 |
|
Pre-assembled signal cable PPU 161.3 – handwheel, length 1 m |
1 |
6FX8002-2BB01-1AB0 |
|
Pre-assembled signal cable PPU 161.3 – incremental spindle encoder (TTL), length 7 m |
1 |
6FX8002-2CD01-1AH0 |
|
SINAMICS V70 |
||
|
SINAMICS V70, Irated 4.6 A |
2 |
6SL3210-5DE16-0UA0 |
|
SINAMICS V70, IN 7.8 A |
1 |
6SL3210-5DE21-0UA0 |
|
SINAMICS V70 spindle3), Irated 19.6 A |
1 |
6SL3210-5DE22-0UA0 |
|
Pre-assembled signal cable SINAMICS V70 – incremental encoder in SIMOTICS S-1FL6 feed motor, length 10 m |
3 |
6FX3002-2CT12-1BA0 |
|
Pre-assembled power cable 4 × 2.5 mm2 |
3 |
6FX3002-5CL12-1BA0 |
|
Pre-assembled signal cable SINAMICS V70 – brake in SIMOTICS S-1FL6 feed motor, length 10 m |
1 |
6FX3002-5BL03-1BA0 |
|
Pre-assembled signal cable SINAMICS V70 – incremental encoder in SIMOTICS M-1PH1, length 10 m |
1 |
6FX3002-2CT30-1BA0 |
|
Power cable 4 × 4 mm2, sold by the meter, (optional)4) |
1 |
6FX5008-1BB31-1DA0 |
|
SIMOTICS motors |
||
|
SIMOTICS S-1FL6 feed motor, 8 Nm, 2000 rpm, incremental encoder, plain shaft, without holding brake |
2 |
1FL6064-1AC61-2AG1 |
|
SIMOTICS S-1FL6 feed motor, 15 Nm, 2000 rpm, incremental encoder, plain shaft, with holding brake |
1 |
1FL6067-1AC61-2AH1 |
|
SIMOTICS M-1PH1 main spindle motor, 48 Nm, 1500 rpm, incremental encoder, plain shaft |
1 |
1PH1105-1LF12-0GA0 |
